Corrugated Roll Forming Machine

Description:

Corrugated Forming Machine is a color-coated steel plate that is cold-rolled into various wave-shaped pressed leaves. It is suitable for industrial and civil buildings, warehouses, impressive buildings, roofs, walls, and interior and exterior wall decoration of large-span steel structures. It has the characteristics of lightweight, high strength, rich color, convenient and quick construction, anti-seismic, fireproof, rainproof, long life, and maintenance-free.


Product Detail

Product Tags

Main Character

♦ Completely automatic cutting.
♦ Easy installation, good performance.
♦ Low noise, high efficiency.

Corrugated Roll Forming Machine11
Corrugated Roll Forming Machine12
Corrugated Roll Forming Machine13

Introduction of product operation steps

Hydraulic de-coiler → roll forming → hydraulic punching (2sets) → cutting →curing machine → product

corrugated roll forming machine-06

Product introduction

application
Corrugated Roll Forming Machine-01.webp

This Corrugated roll forming machine can produce corrugated metal tiles for industrial and civil buildings, warehouses, special buildings, large span steel roofs, house walls and exterior decoration, etc. It also includes some villages, supermarkets, hotels, exhibition halls, home buildings, shopping mall shutters and other buildings. Corrugated roll forming machine, roofing tile surface is very smooth and beautiful, the roof is not scratched. It has beautiful, external, classical appearance and elegant taste. We supply the best machine for our customer.
We have dozens of profile model machines for this series of molding, and we can design various profiles and accessories according to customers' requirements.

Product parameters

No Item Description
1 Material thickness 0.3-0.8mm/ 2-4mm
2 Forming speed 12-15m/min / 25-30m/min /15m/min
3 Roll station 18 stations
4 Main power 5.5KW/ 7.5KW/ 37KW
5 Hydraulic power 3KW/ 7.5KW
6 Control system PLC Panasonic
7 Drive By Chain/ by gear box

Main Technical Specification

Material thickness: 0.3-0.8mm Material thickness: 0.3-0.8mm Material thickness:2-4mm
Working speed: 12-15m/min Working speed: 25-30m/min Working speed: 15m/min
Roll station: 18 stations (depend on the profile) Roll station: 18 stations (depend on the profile) Roll station: 18 stations (depend on the profile)
Main power: 5.5KW Main power: 7.5KW Main power: 37KW
Hydraulic power: 3KW Hydraulic power: 3KW Hydraulic power: 7.5KW
Control system: PLC Panasonic Control system: PLC Panasonic Control system: PLC Panasonic
Drive: by chain Drive: by chain Drive: by gear box
